Awnings
Australia
AUSTRALIA is perfect for big terraces. Simple construction and high-quality workmanship make it suitable for commercial applications. The awning’s folding arms are installed on aluminium brackets made through pressure casting. The precise manufacture of the articulated joints, as well as the plate link chain applied in them, provide durability and dependable operation of the awning. A central support for the roller tube in the case of particularly wide awnings compensates for tube deflection, thus providing good fabric tension. The construction is supported by a square steel beam that gives relative freedom of bracket location and simplifies the awning installation. The construction of the awning is powder lacquered in white, graphite, silver with graphite finish, beige, and brown. There is a possibility to use overlapping arms in this awning.
Technical parameters
CASSETE: no
ROLLER TUBE: 70mm and 80mm diameter
MOUNTING: wall, ceiling, roof
PROJECTION: 1.6m; 2.1m; 2.6m; 3.1m; 3.6m
MAXIMUM PROJECTION: 3.6m
MAXIMUM WIDTH: 7.0m
MINIMUM WIDTH: projection + 0.35m
ARMS: folding, aluminum, with springs and plate Flyer’s chain, folded arm levelling, in case of overlapping arms minimum width = projection - 0.4m
OVERLAPPING ARMS: yes
TILT ANGLE: 5° ~ 60°
OPTIONAL HOOD: no
CONSTRUCTION COLOUR: powder coating: white, beige, brown, graphite, silver+graphite
FABRIC: over 100 patterns
MANUAL OPERATION: crank: 1.5m; 1.8m; 2.2m
AUTOMATIC DRIVE: motor, motor with manual override, remote control, wind-sun weather control
AUTOMATIC VALANCE: standard height 21cm (±0.5cm), shape like in the provided template, maximum height 40c
